slide switch SS23D07, horizontal side-pull sliding switch, floor lamp three-position switch, power band switch
Five Advantages Of Products
- high quality materials
- high quality products
- strict quality control
- low-volume production
- mass production
Product Details
Control type: Bipolar 3-bit
Rated current A: 0.3A
Rated voltage V: DC50V
Insulation resistance: ≥100MΩ
Dielectric strength: 250VAC/min
Contact resistance: < 100Ω
Operating force: 250gf±100gf
Stroke: 2.0mm
As the products come in different sizes, please contact us for any other information
